CORTEX® INDUSTRIAL SYSTEMS CONTROL UNIT Model CORTEX-XXX

(NOT FOR NEW DESIGNS.  See Cortex® LT V2)

General Description•Specifications•Application Example•Models/Dimensions/Connections

General Description

Combining years of Carotron system engineering experience with microprocessor technology, the CORTEX® provides a simple programmable solution for many drive system applications in industrial systems control.  Each model provides application specific software along with:

• 2 Analog inputs
• 2 Frequency inputs
• 6 Digital Logic inputs
• 4 Relay outputs
• 1 Analog output
• 1 Frequency output
• 1 IIC Expansion Bus
• 1 RS-232 Communications port

Applications

Constant Tension Center Winder Control

Dancer Position Control

Center Unwind Control

Loadcell Tension Control

Electronic Speed Reference Control

Custom Applications for Industrial Systems Control

*Note: Carotron has released the new CORTEX® LT, which can be used for new or existing applications.
