Modbus RTU Module


General Description

Models
Modbus Slave

The MicroManager MM3010-MBS is a microprocessor based  Modbus® RTU I/O expansion module. This Modbus RTU module is designed for use in industrial SCADA (Serial Control And Data Acquisition) applications. It provides analog and digital I/O plus frequency inputs that can be accessed/controlled over an RS485 Modbus® RTU network. Combined with an appropriate HMI Touchscreen, it becomes a simple, but powerful, data acquisition & logging system.

Model MM3010-MBS provides two Modbus® RS485 slave ports.  The main port (located on the terminals) is typically used to connect to the primary Modbus®  network. Setup and configuration is accomplished by using Carotron’s MicroLink software.  A serial port is required on a PC to connect to the MM3010-MBS.  If a serial port is not available, a USB to Serial Adapter can be used. The Modbus® RS485 communications port allows for all parameters to be read and for selected parameters to be changed

VIEW INSTRUCTION MANUAL
View Brochure

For more information about this product,
call 1-888-286-8614 or e-mail us today!

MicroManager 3010 MBS QR Codes
