Distance Measurement Tool

General Description

Model SMU100-XXX is a distance measurement tool that uses ultrasonic technology to detect and measure targets up to 30 feet away. An Environmental Grade electrostatic transducer patented by Polaroid for use in their auto-focus cameras combined with Carotron industrial grade interface and processing circuitry provides a distance measurement tool with reliable and accurate operation in a wide range of applications. Crystal time-based digital counters display distance to 1/10 foot resolution and give 12- bit resolution to the analog voltage output. The output voltage can be sourced from on-board positive or negative supplies or an external voltage can be multiplied by a percentage of distance. Distance is divided into four ranges to give maximum output resolution and to establish “valid echo” distances beyond which objects are ignored. The distance to an out-of-range object will be displayed up to 35 feet but the output will not change. Continued operation “out-of-range” for a programmable time period from 1 to 15 seconds will energize a Fault relay whose contacts can be used by the customer to sound an alarm, stop a machine, etc.

Models and Descriptions

Model Number
Description
Approx.
Shipping Wt. (lbs.)
SMU100-020
Sonictrac¨ control board, NEMA 12 transducer enclosure and 20 ft. cable
7
SMU100-040
Sonictrac¨ control board, NEMA 12 transducer enclosure and 40 ft. cable
8
SMU100-060
Sonictrac¨ control board, NEMA 12 transducer enclosure and 60 ft. cable
8
SMU100-080
Sonictrac¨ control board, NEMA 12 transducer enclosure and 80 ft. cable
9
SMU100-100
Sonictrac¨ control board, NEMA 12 transducer enclosure and 100 ft. cable
9

Stainless steel transducer enclosure available on special order – change last number of part number from 0 to S

VIEW INSTRUCTION MANUAL
View Brochure

*Related Products: Sonictrac® Pro (Model STP200-000)

For more information about this distance measurement tool,
call 1-888-286-8614 or e-mail us today!
