Carotron Brand Products are Made in USASignal Isolation Card (Signal Isolator)
Model C10209-000

General DescriptionStandard FeaturesSpecificationsApplication ExampleDimensions/Connections


General Description

Signal Isolation Card Model C10209-000The Model C10209-000 Signal Isolation Card (signal isolator) is designed for applications in which signal conditioning is required in a single channel while electrical isolation between the input and output signals is maintained. Designed for a wide variety of input signals, Model C10209-000 can accept five types of inputs:

  • Potentiometer
  • D.C. Voltage
  • D.C. Current
  • Sine Wave Frequency
  • Square Wave Frequency

Each input signal is conditioned by scaling circuits that can be modified via multi-turn OFFSET, BIAS and GAIN potentiometer adjustments on the Signal Isolation Card. Terminal strip connections are provided for an external Trim pot. and an external Summing Input. A single turn TRIM RANGE adjustment is supplied on the Signal Isolation Card to limit the range of the external Trim pot. The output circuit can be configured to source either a voltage or a current. Typical output ranges for this signal isolator are 0 to +10 VDC, 0 to 20 mADC or 4 to 20 mADC.

VIEW INSTRUCTION MANUAL
View Brochure

*Note: Carotron has released a new Din-Rail mountable Signal Isolation Module (Model SIM200-000), which can be used for new or existing applications.

For more information about this product,
call 1-888-286-8614 or e-mail us today!
